ANTENNA SPECIFICATIONS FOR APPROVAL

General Descripion

• Type No. : HYM-889
• Part No.: N/A

Electrical Properties

• Frequency Range :900~1800 MHz
• Nominal Impedance: 50 Ω
• V.S.W.R: <1.5
• Antenna Average Gain: 2.5dBi

Mechanical Properties

• Antenna Type: INSIDE-ON-GLASS(PATCH Antenna)
• Connector Type: FME or SMA
• Cable Type: RG174U 3M
• Antenna Color: Black
• Operating Temperature Range: -40°C~+80°C
